Introducing the Pinecil V2 USB C Soldering Iron with OLED Display and Type B2 Tip! This compact and powerful soldering iron is perfect for all your DIY projects, repairs, and prototyping needs. The Pinecil V2 is an upgraded version with enhanced performance and features, making it the perfect tool for any electronics enthusiast or professional.
The Pinecil V2 features an OLED white color monochrome display with a size of 0.69 inches and a resolution of 96x16pixels, giving you all the information you need for your soldering work. It is powered by the Bouffalo BL-706 chipset and a 32-bit RV32IMAFC RISC-V “SiFive E24 Core” @ 144 MHz CPU, providing fast and reliable performance.
This soldering iron is built with a plastic body, making it durable and lightweight. It has a black case with a green sleeve for a stylish and unique look. The Pinecil V2 weighs only 28g with a solder tip and 18g without a solder tip, making it easy to handle and maneuver.
The Pinecil V2 is equipped with a type B2 tip, with a length of 86mm and a weight of 8.2g. It is also capable of receiving power from either USB-C port or barrel jack, with USB-C supporting GPIO break-out. The Pinecil V2 has FCC, CE RED, and ROHS certifications, ensuring quality and safety.
In the package, you will receive a Pinecil Soldering Iron and an ST (Short Tip)-B2 Soldering Tip. The dimensions of the package are 15cm x 9cm x 2.2cm, and the weight is 80 grams.
Order your Pinecil V2 USB C Soldering Iron with OLED Display and Type B2 Tip today and take your soldering work to the next level!
Package Contents:
- Pinecil Soldering Iron
- ST (Short Tip)-B2 Soldering Tip
Specifications:
- Build: Plastic with metal clip (handle)
- Color: Black (case)/ Green (Sleeve)
- Chipset: Bouffalo BL-706
- CPU: 32-bit RV32IMAFC RISC-V “SiFive E24 Core” @ 144 MHz
- Display Type: OLED White Color Monochrome Display
- Display Size: 0.69 inches
- Display Resolution: 96x16pixels
- Internal Flash Memory: 192KB
- System Memory: 132KB SRAM
- Expansion: None
- Power Ports: USB type C: PD and QC 3.0 12V-20V 3A, Barrel Jack: DC5525, 12V-24V DC 3A
- Tip Type: B2
- Tip Length: 86mm
- Tip Weight: 8.2g
- Certification: FCC, CE RED, ROHS
- Dimensions (with solder tip): 155mm x 12.8mm x 16.2mm
- Dimensions (without solder tip): 103mm x 12.8mm x 16.2mm
- Weight (with solder tip): 28g
- Weight (without solder tip): 18g
Important Warnings and Cautions for Soldering Equipment:
- This equipment is designed for use by experienced electronics technicians. We do not provide advice on specific applications.
- The user assumes all risk and responsibility for the application of the equipment.
- Any warranties offered are limited to the replacement or refund of the product.
- Safety glasses must be worn at all times when working with soldering equipment and materials.
- Adequate ventilation should always be ensured when working with soldering equipment and materials.
- Avoid inhaling flux fumes emitted during soldering, as they may cause pulmonary irritation or damage.
- This product may contain chemicals known to the state of California to cause cancer and/or other reproductive harm. Take necessary precautions and follow safety guidelines.
Please read and adhere to these warnings and cautions to ensure safe and responsible usage of the soldering equipment.
